Yeah. It helps if you can sell your chip at $30k, more than an entire TSMC wafer.
Also note Nvidia is (still) using a 5nm-class node, half a decade old now (mature, depreciated, high-yield). Instead, Intel's idea with PVC was to be the 7nm (I4) *lead* product. Glenn K. Lockwood
Ben Bajarin I’ve asked and so far, no one has sent me that electron microscope image that shows one 3nm transistor.
Maynard Handley 🟦 witeken Andreas Schilling 🇺🇦 🇮🇱 What do you mean with 'we dont know the area'?
A14 is 11.8B transistors on 89.75mm² so 131Mtrans/mm²
A17 is 19B transistors on 113.99mm² so 166.68Mtrans/mm²
This is a 1.27x increase
