#_carry 015 逆作用ピンセットにLEDをはさんでハンダ付けをしている様子です。ケーブルの太さは0.08mmです。

SIS 85C407

Interesting, it seems there is another revision/version (?) imaged by someone else on sip: siliconpr0n.org/map/sis/sis85c…

SIS 85C471

GI AY-3-8500 Pong, and 5 other games on a chip!

High res: siliconpr0n.org/map/gi/ay-3-85…

Nuvoton MS51FB9AE 8-bit MCU

Nuvoton MS51FB9AE 8-bit MCU Multi-focus panorama at maximum optical resolution (60x/1.40 oil objective). ic.onidev.fr/map/nuvoton/MS…

Thomson EF9345P

High res: siliconpr0n.org/map/thomson/ef…

Tell me why this thing needs to cost $4k 💀 Experts here?

Look what monstrosity we can have today from Analog devices for $14,51 ~800MHz to 1GHz DSP lol What excuses we have now if we compare it with the other 4k old one. I want to use those everywhere 😄

For nerds who like technology and super diamonds 💎 The super diamond, the semiconductor of the future. youtu.be/FHHATmUdCx4?si…

FA 7612 CP - Fuji Electric | Switching Power Supply Control IC For step-down power-supply circuits. This one has interesting colors 😛

Diagrams from datasheet and chip package.

In this video, edison science corner goes hands-on with the new Arduino Nano R4. Watch as he takes a closer look at the board's features and how to get started: youtu.be/y3obEIoy1CU

This guy is definitely worth a follow! He converts toy cars into remote control cars by building teensy tiny electronics to put in them! I *wish* my soldering was that good!

Amplifiers, where analog becomes Art. AUDIO SYSTEM AS4120 | Made in Italy 🇮🇹 4x120W Class A amplifier.

The 32.768khz Clock quartz inside that 1mm x 3.8mm metal cylinder "Laser tuned on the left". Looks familiar with the last one I decapped but this is much extreme, 0.5mm x 2.7mm. Enjoy.

DC Motor on thermal.
