It’s a #silicondoodle !

What followed my „easter egg hunter“ post was a request for an interview by the National Public Radio (NPR)… and today, the article about the topic was published! Enjoy reading!

npr.org/2024/04/16/124…

youtu.be/2gM3IMeYL7o?si…

It´s a 8080!
I also stitched 70 microscopy pictures to one picture...beautiful transistors...

It´s an 8080!
I did not dare decapping the original Intel 8080 but some time ago, I opened a NEC version - the D8080AF from 1976. How do you like the macro shot?

It’s an #Intel 8080!
50 years ago, to this date, Intel launched the 8bit 8080 CPU. 🥳
Anyone has any good memories using this processor?

Looks like a great moment!

It´s an #Intel #486DX !
35 years ago to this date, Intel announced its second 32-bit processor called the i486!
I made a small video highlighting some feaures about this milestone in #CPU history!
Enjoy!

Sneak preview

It’s a #cartwheeler ! 🤸‍♀️
The largest chip used in the S4 is a #Siemens PMB 2705 which is a GOLD - GSM One-chip Logic Device. The #IC contains a hidden Easter egg in the form of a cartwheeler.
Siemens (now Infineon) had one of its regional headquarters in the German city Düsseldorf

It’s a #Siemens S4 mobile phone!
Only one of the four Siemens ICs has a #silicondoodle . You recognise it on the broken IC?
The memory ICs are also ‚empty‘.
The second doodle (the hatching dino) is on the #AnalogDevices Mixed Signal processor which takes the function of speech

It’s an #EasterEgg !
Those vintage mobile phones have many ICs…the S4 from Siemens (1995) counts 7. Two of the chips have an #easteregg hidden inside.
Watch my video to find them!

youtu.be/zjgRZocKYtI?si…

4/n

Nutritional Yeast Infection 🌱 Druthers Haver Y'all joking but there really is a tradition of printed circuit board Easter eggs.

Yes and I am one of these Easter egg hunters…

youtu.be/mR43YzKBRFc?si…

#HappyEaster !
If you wonder in which device I found the hetching 🦖, have a look at the video I posted!
There is also an Easter egg hidden in the video…will you find it?
3/n

youtu.be/zjgRZocKYtI?si…

It’s a #HetchingDino !
Do you know why epoxy is such a great material for encapsulating #silicon #chips ? There must be many reasons but I find it amazing when a #die is decapped and the epoxy mold shows all fine details of the silicon…just mirrored… 🪞

It’s a #HetchingDino ! 🦖
The Easter 🐣 weekend is near and I found my easter egg already!
It was hidden on an #AnalogDevices chip, namely the ADSP-21MSP59.
Where do you think that chip is used? Small hint: it is a Mixed Signal Processor…guess the application! 1/n

How a well placed light source can make an awesome „glowing pcb“ picture 🤩

It‘s a #mobile !
What powers mobile phones? I guess it is these kind of integrated circuits like the IC i76502 made by #DialogSemiconductor (now part of Renesas)…Why would otherwise this cute #silicondoodle be placed on that chip if not for a mobile application?
Dialog was a

Very interesting, later released #AMD #Athlon Thunderbirds, have a new revision of the top metal layer (the previous top metal layers were made of aluminum).

6309 (aluminum) vs 7309

DS80C320 from Dallas Semi, macro shot of the die and higher magnifications of the logo and contributing designers…
