Looking for a coupling #A6 #Stepperonline #hiwin

New easy DIY task rising from the horizon when LSA1 comes. Measuring+inspection of tool in the spindle. I like to use Mitutoyo Canada and hope that LWD 7.5x objective do its job well, when usage this objective for full frame photos was dissapointing. #ACCUD #DIY And result is 42.

Lets print something to join it for tool measuring DIY part. #mitutoyo #raynox #omegon

First part of something to join items for measuring /inspection tool. #mitutoyo #raynox #omegon

Test print of first part is done and it is close to good. #mitutoyo #raynox #omegon #freecad

Afternoon at the forest

Mushroom at the backlight from mobile phone

Some first model printed from PET-CF after the weekend. printables.com/model/1459585-… #FreeCAD #APUS2 #TAP #XOL

Tonight spider with Mitty 20x LWD 12in.cz/fotografie/obr… #třesavka #spider #Pholcus #mitutoyo #photography

Going on to the next step, preparation of the rest pieces for precize 12x20" sheet #ilford film cutter to two pieces with 12x12" and 8x12" dimensions.

Cutter with KwTrio A2 as base plate. #FreeCAD

Today just TestCUT instead of #FreeCAD

Added holders under the desk for storeaging of cutter in the darkroom. #FreeCAD #3DPrinting

I am just amazed how fast and accurate is Helicon Focus in version 8. Video show dropping of 336 TIFF files, 172 MB (30 Mpx) each file and it tooks not even whole minute to get result. #heliconfocus #tick #kliste #microphotography #photomicrography

Few years from shooting i completed final stacked and stitched photo of tick. Taken with 20x LWD Mitutoyo. Full resolution is 257Mpx. 12in.cz/fotografie/obr… #mitutoyo #tick #kliste #microphotography

I am getting to know using of #Pico This night just simple test on StandBy power supply from TDK-Lambda Americas power source for 600W LED. #pimoroni #vscode #c

As i don't have MMU or toolchanger and i would like to print my own bellows, i tested idea to prepare PLA spacers that will be added at pauses to the printed TPU 95A part. Prooved and it works. #FreeCAD #3dprinted #bellows

Completed XoL toolhead (used PET-CF and PPA-CF printed parts and Phaetus Dragon Voron hotend with SC phaetus noozle) and so it is ready for test. #xol #toolhead #3dprinted #phaetus
