If you've even wondered what a 4:1 Balun looks like for a 250kW Shortwave Transmitter by RIZ Sender 94 3 monthly Balun Inspection at Woofferton It's about 2m tall

Servicing the pen grid box on S82 Circa 1979-1981 Marconi B6124 300kW SW Transmitter

Still on the Pen stage Now changed the valve out!

Sender 61 at Skelton, Sender 107 at Kranji and soon to be Sender 93 at Woofferton! Slowly being installed at Woofferton

I do like this rig!! Sender 82 - Marconi B6124

Balun and feeder being installed Sender 93 at Woofferton

Forgot I had this video Just shows how quickly a BNC can be terminated!! Crimp type, with LMR195 I didn't heat shrink it on this occasion, but I normally use glue lined heat shrink, well worth the extra money!

Coax is being connected to the Balun! Surely some RG58 would work.....😁😁😁 It amazes me how big the inner conductor is!!

Friday night Out on a date with this old girl Frequency changed from 17670 to 17640kHz, ready for her 19:29:30 service in Hausa for 1 hour!

All about the Krone today!! Trying to the get the control wiring sorted for the "new" Sender 93 The old man, Dave G4OYX is here this week to sort the audio!! Cat 6 has been terminated to sockets, and has tested OK! I'm just thankful I didn't have to terminate RJ45!

Getting ready for B24 season S95 is going to be a cover option for 25700kHz That's a first, never seen the final anode coil for 26MHz

The other hobby I have, is playing a Bass Guitar I currently use a Wah, Chorus & Tuner Pedal, however, if I could get this set up, I'd be rather pleased!

Never mind the shepherd Red sky at night, transmitter engineer's delight

Suspect the ground plane will be fairly good at the moment!

Tinkering with an Allstar Node Testing the range S9+ in the George and Dragon, Much Wenlock, Shropshire

Sadly one of the Audio Processors went faulty today for Sunshine Radio! A trip to the studio, to pick up the spare Great to see Nick on the breakfast show in full flow

80 seconds to put on an N type! LMR195, Soldered Pin and Crimp Outer Glue lined Heat Shrink

My rig is bigger than yours 😂😂😉

An evening shift for me today! Making sure that the BBC World Service Mid-Winter Antarctica Special on 12065kHz is transmitted from Woofferton, Shropshire, UK to all those working for the British Antarctic Survey 🐧! Very proud to be part of this! Cerys Matthews RSGB

Back to July this year when I graduated with a HNC Distinction in Electronics and Electrical engineering from Shrewsbury college! This was a 2 year part time course, as part of my Transmitter engineering training! Those in the know will recognise Dad G4OYX! Big shoes to fill!
