working.... New Video： Huawei Car Chip（990A&9610A) analyze Huawei Ascend 910C analyze

Hexgon Package decaped

Hexgon Package decaped 2/2 P1:die1 shot P2:die1 diemark P3:die2 shot P4:die2 diemark

AMD Threadripper 9995WX IOD Dieshot Thanks By@ASUS Tony 俞元麟 give chip Thanks By@万扯淡 Decap Kurnal Layout P1： IOD Diesize：16.45mm x 25.94mm P2：CPU Diesize：7.76mm x 9.05mm

Huawei Ascend 910C chip analyze TSMC N7 Family Same chip with 910B Video on Youtube： youtu.be/0feji7gMrh8?si…

Kirin X90&Kirin 9610A Dieshot diesize 12.82x 16.34 technology：SMIC N+2

Common Automotive Chips Samsung： Exynos Auto V7/V9 Exynos Auto V720/V920 Qualcomm: SA8195P SA8295P SA8650P Huawei: Kirin 9610A Siengine: SE1000

Huawei New server chip KunPeng 930 Tech： CPU Die ：TSMC N5 Family IO Die ： SMIC 14? Analyze chip Video in Bili and Youtube youtu.be/ALXcH1uXHgY

Raipidus share the data with 2nm（Named 2HP) so that，we can know the NEXT Gen process technology in Logic Density

Qualcomm SM8850 8Elite Gen5 Doing....

Qualcomm SM8850（8Elite Gen5） Dieshot Diesize 10.57mm x11.94 mm

MediaTek Dimensity 9500 Dieshot Diesize 10.88x12.92=140.79mm2 Photo#1 D9500 Dieshot Photo#2 8Elite Gen5 VS D9500 Photo#3 D9500 VS D9400 VS D9300

Apple N1 chip analze Doing

about the Arduino UNO Q QRB2210 Bottom mark: HU211HMP H = GlobalFoundries U = Shanghai Amkor Packaging Manufacturing/Packaging Date: Week 11, 2022

A19Pro Dieshot Chip by @1214258a Die shot by @万扯淡 Layout by Kurnal Die size：8.03mm x 12.29mm =98.69mm2

if.... have Mali G925 MP24，it will more than 50mm2 size haha

thats will be too expencive

「Kurnal」Analysis Report on the Dimensity 9500 Chip youtu.be/FlaPFrkgRgk
